50M2 RESIDENCE

Concept

Project type -  Residence For Pankaj Kumar

​

Plot Area - 50 Sqmts

​

Plot Location - Preetam Nagar, Prayagraj Uttar Pradesh India

​

Project Status - Completed

​

Design Team - AAA Design Studio

2023.5.5_Proposed Elevation A_Low Res Website.jpg

introduction

Site Location
Source Google Map

About the Project

Site Location.jpg

50 sqmts. residence, as the name suggest the residence is designed on the plot area of only 50 sqmts.



Client's Brief and Requirements :

The client approached us with a very predictive requirements, things turned around when during the construction client wanted to change the way staircase was designed from internally to an external unit. The client wanted to have a cozy comfortable house for his family. A daughter, a son, a wife and frequent visitor from his nearby village.

Keepin in consideration the requirements we proposed to client to have multiple floors where we can divide the function of the residence in a vertical fashion. The ground floor thus became a place for entertaining guest with a beautiful lounge area and a guest bedroom with a toilet, which may be used as an elderly room when guest are not around.

​

The first floor consisted of two bedrooms while the central lounge becomes the heart of the residence with the kitchen and the dining area at the centre of the floor. The first floor enjoys the beautiful overlooking balcony towards the central park area. Thus extending the house beyond the plot line.

FLOOR PLANS

1

2

3

4

5

6

lift

road

Ground Floor Plan

1

2

3

4

5

6

7

8

stairs

lift

1st - 2nd Floor Plan

Terrace Floor Plan

1  Ramp
2  Water Body
3  Car Parking
4  Visitor's Toilet
5  Electrical and Plumbing Shaft
6  Servant's Room

01_Section 01.jpg

1  Drawing _ Dining Area
2  Common Toilet
3  Bedroom 01
4  Toilet 02
5  Bedroom 02
6  Balcony
7  Kitchen
8  Study Room

Section -01

Roof Plan

SECTION

2020.8.2_Sectional Staircase.jpg

section X-X
